Technical Data

Laser receiver

LR 7

Article number

‎3 601 K69 J..‎‎‎‎

Working rangeA)

5–X mB)

Reception angle

90°

Reception accuracyC)

  • "Fine"

±1 mm

  • "Coarse"

±3 mm

Operating temperature

–10 °C to +50 °C

Storage temperature

–20 °C to +70 °C

Max. altitude

2000 m

Relative air humidity max.

90 %

Pollution degree according to IEC 61010-1

3D)

Batteries

2 × 1.5 V LR6 (AA)

Approx. operating time

30 h

Weight according to EPTA-Procedure 01:2014

0.15 kg

Dimensions (length × width × height)

73 × 28 × 137 mm

Protection rating

IP54 (dust and splash-proof)

A)

The working range may be reduced by unfavourable environmental conditions (e.g. direct sunlight).

B)

X: Maximum working range for operation with laser receiver according to the operating instructions for the Bosch line laser or Bosch point and line laser that is used

C)

Dependent on the distance between the laser receiver and the line laser/point and line laser

D)

Occurrence of conductive deposits or dry, non-conductive deposits which become conductive when an expected level of condensation occurs. Under such conditions, the product is usually protected from direct sunlight, precipitation and high wind pressure but neither temperature nor air humidity are being monitored.

For clear identification of your laser receiver, see the serial number (12) on the type plate.
